MD24
• Output Power(Stereo)
4 x 2000W at 8Ω
4 x 3350W at 4Ω
4 x 5300W at 2Ω
• AC Power Operating Range
100V-240V/50-60Hz
- Commodity name： MD24
Overview
MD24 delivers outstanding power and control in a compact design, offering up to 4×5300W output and flexible 100V/70V/low-impedance operation. With a built-in 96kHz DSP, 4.3" touchscreen, and optional Dante, it supports matrix and bridge modes, real-time remote monitoring, and web-based control via Mconsole 3.0. FIR filters, adjustable gain, and robust protection ensure reliable, precise audio performance—perfect for high-demand fixed installs and touring sound reinforcement.
Specifications
| Output Power | 4 x 2000W at 8Ω(stereo) |
| 4 x 3350W at 4Ω(stereo) | |
| 4 x 5300W at 2Ω(stereo) | |
| 2 x 6800W at 8Ω(bridge) | |
| 2 x 9000W at 4Ω(bridge) | |
| Maximum Output Voltage | Stereo 126.5V Bridge 233V |
Constant Voltage Output | <0.05% |
Damping Factor | >5000 @ 20-200Hz |
Slew Rate | 50V/µs @8Ω |
Frequency Response | 20Hz-20kHz (±0.5dB) @1W, 8Ω |
S/N Ratio | >104dB |
Channel Separation | <-94dB @1kHz, 0dBu |
Common Mode Rejection Ratio | >60dB @1kHz, 0dBu |
THD | ≤1% @1W to full power |
Input Sensitivity | 26dB~44dB |
Input Impedance | 20kΩ |
Maximum Input Level | 20dBu / 7.75Vrms |
Input Connectors | 4×Analog input (support LINK OUT) |
Optional Network Audio | 8-channel Dante (input/output supported) |
Output Connectors | 4×NL4 speaker connectors |
DSP Sampling Rate | 96kHz / 24bit |
Display | 4.3-inch IPS capacitive touchscreen |
Protection System | Short-circuit ; Overheat; Overload; Overvoltage; Undervoltage; Soft start; Limiter |
Status Indicators | Power; Signal; Peak; Limiter; Protection |
Cooling System | Front-rear convection with temperature-controlled fan |
Operating Temperature | -20°C to +40°C |
Operating Humidity | 20%–80% RH |
| AC Power Operating Range | 100V~240V/50-60Hz |
Max Tolerable Voltage | 270V |
| Dimensions ( HxWxD ) | 88x482x548 mm |
Packing Size ( HxWxD ) | 175x585x684mm |
Net Weight | 16.4 kg |
| Gross Weight | 20.4 kg |
