VS212SUB MAX
• Drivers
2 x 12" neodymium
• Max SPL (Peak)
130dB
- Commodity name： VS212SUB MAX
Overview
VS212SUB MAX is a high-power subwoofer designed to extend low-frequency response down to 40Hz. Featuring dual 12-inch neodymium drivers and an 1800W Class D amplifier, it delivers deep, impactful bass with stable performance. The advanced DSP control ensures precise low frequencies, making it ideal for environments that require powerful bass reproduction.
VS808 MAX and VS212SUB MAX are designed to function both as a combined audio solution and as standalone units. Each speaker comes with an integrated amplifier module, providing flexibility in system configuration and tuning. This allows for scalable setups, making it suitable for both temporary and permanent installations in a variety of venues.
There are three setup configurations: stacking, with support poles, or hanging, providing flexibility for any venue. The modular design supports scalable and customizable sound reinforcement for varying acoustic needs.
▶️ Installation Guide on Youtube
Specifications
| Drivers | 2 x 12" neodymium |
| Frequency Response (-3dB) | 40Hz～300Hz |
| Dispersion (-6dB) | / |
| Max SPL | 124dB (continuous)/130dB (peak) |
| Power (RMS standards) | 1800W |
| Amplifier Circuitry | Class D |
| DSP Sampling Rate | 96kHz/24-bit |
| DSP Input Channels | 1 in 1 out |
| AC Power Operating Range | AC100～240V，50/60Hz |
| THD | ≤0.05% |
| Input/Output Connectors | XLR-F/M |
| Dimensions ( HxWxD ) | 706 x 400 x 580 mm |
| Net Weight | 44kg |
Dimensions
