VS-210
• Drivers
LF: 2 x 10" neodymium
HF: 2 x 1.75" neodymium
• Dispersion
Hor. 80° x Ver. 10°
• Max SPL（Peak）
136dB
- Commodity name： VS-210
Overview
The VS-210 is an active loudspeaker featuring a two-channel amplifier module with a high-performance DSP processor. The DSP allows for customizable settings, simplifying system setup and ensuring optimal performance in various applications and configurations.
Equipped with dual 10-inch neodymium low-frequency drivers and a 3-inch neodymium high-frequency driver, the VS-210 delivers powerful mid-bass and clear highs. Its design, including a phase plug and constant-path planar waveguide, enhances energy efficiency, improving mid-frequency performance and overall frequency response.
When arranged in vertical arrays, the VS-210 increases sound coverage and efficiency. The robust birch plywood enclosure is treated with a polyurea coating for moisture resistance and durability. A protective metal grille and acoustic mesh further safeguard the system.
Ideal for medium to large venues—such as theaters, conference halls, and outdoor events—the VS-210 pairs perfectly with the VS-18SUB for extended bass response.
Specifications
| Drivers | LF 2x10"(250mm) neodymium HF 1x3"(75mm) neodymium |
| Dispersion | Hor. 80° x Ver. 10° |
| Frequency Response (±3dB) | 70Hz~18kHz |
| Max SPL | 130dB (continuous)/136dB (peak) |
| Power Amplifier Modular | 1 in 2 out DSP , Class D |
| Channel and Power | 2 channel，300W/8Ω+900W/8Ω |
| Input Sensitivity | 1.0V |
| Input/Output | XLR(balance) |
| AC Power Operating Range | AC110V~250V，50Hz/60Hz |
| Dimensions ( HxWxD ) | 274 x 730 x 401 mm |
| Net Weight | 31.5 kg |
Dimensions
