EX1300
• Output Power(Stereo)
4 x 1300W at 8Ω
4 x 2100W at 4Ω
4 x 2500W at 2Ω
• AC Power Operating Range
200-240V/50-60Hz
- Commodity name： EX1300
Overview
EX1300 is a high-performance switching power amplifier designed for professional sound systems. With output power of up to 5000W in bridge mode, it delivers impressive clarity across a frequency range of 20Hz-20kHz. Featuring a Class ITM power module, the amplifier ensures efficient power delivery and exceptional sound quality. Its intelligent protection circuit includes features such as soft start, overload, short-circuit, and peak current limit to safeguard both the amplifier and connected equipment. With flexible input sensitivity options and a rugged design, EX1300 is ideal for demanding environments like live events and large venues.
Specifications
| Output Power | 4 x 1300W at 8Ω(stereo) |
| 4 x 2100W at 4Ω(stereo) | |
| 4 x 2500W at 4Ω(stereo) | |
| 2 x 4200W at 8Ω(bridge) | |
| 2 x 5000W at 4Ω(bridge) | |
| Frequency Response | 20Hz-20kHz, +0/-1.5dB |
| Total Harmonic Distortion | ≤0.05% |
| S/N Ratio | ≥80dB |
| Input Sensitivity | 0.775V/1V/1.4V, 38dB/32dB/26dB |
| Input Impedance | 20K/10K (balanced / unbalanced) |
| Output Circuitry | Class ITM Power Module |
| Dimensions ( HxWxD ) | 88 x 483 x 480mm |
| Net Weight | 16.5 kg |
| AC Power Operating Range | 200~240V/50-60Hz |
