BT12SA
• Drivers
1 x 12"
• Max SPL (Peak)
127dB
- Commodity name： BT12SA
Overview
BT12SA is a 12" active subwoofer designed to power and complement the BT8 column speaker. It features a dual-channel Class D amplifier (2×700W), onboard DSP, and a built-in 6-input digital mixer supporting mic, line, Bluetooth, and USB. With rich bass extension down to 40Hz, it serves both as a powerful subwoofer and as the control center of the BT8/BT12SA active system. Durable construction and flexible I/O make it perfect for portable setups and fixed installations.
Specifications
| Drivers | 1x12"(300mm) bass |
| Frequency Response (-3dB) | 40Hz～300Hz |
| Frequency Response (-10dB) | 35Hz～300Hz |
| Max SPL | 122dB (continuous)/128dB (peak) |
| Rated Power (AES) | 400W |
| PEAK Power | 1600W |
| Amplifier Circuitry | Class D |
| Amplifier Frequency Response (0/-5dB) | 20Hz~20kHz |
| Amplifier Power (4Ω) | 1400W |
| DSP Sampling Rate | 96kHz/24-bit |
| AC Power Operating Range | 220～240V，50/60Hz |
| Impedance | 4Ω |
| SNR | ≥95dB |
| THD | ≤0.05% |
| Input/Output Connectors | XLR-F/M, RCA, 6.35mm jack |
| Amplifier Output Connectors | 2 four-core professional speaker socket MLF Out 1+ 1- |
| AC Power Operating Range | 220V～240V，50Hz/60Hz |
| Dimensions ( HxWxD ) | 536 x 326 x 516 mm |
| Net Weight | 42 kg |
