E135A
• Output Power(Stereo)
4 x 1350W at 8Ω
4 x 2000W at 4Ω
• AC Power Operating Range
100V-240V/50-60Hz
- Commodity name： E135A
Overview
E135A is a highly flexible and intelligent 4-channel Class D digital power amplifier, offering powerful output and advanced DSP technology. It features high-speed cooling, a 24-bit AD/DA converter, and supports functions such as noise gating, FIR filters, high/low pass filters, and parameter balancing. Through USB or TCP connection, users can remotely control the amplifier, adjust parameters, select sound sources, and access presets via the touch screen LCD. With built-in protection systems, including overheat, short-circuit, and amplitude limiting, the amplifier ensures reliable performance for passive speaker systems.
Specifications
| Output Power | 4 x 1350W at 8Ω(stereo) |
| 4 x 2000W at 4Ω(stereo) | |
| 2 x 4000W at 8Ω(bridge) | |
| Frequency Response | 20Hz-20kHz, ±0.5dB |
| THD | <0.05% |
| S/N Ratio | ≥100dB |
| Damping Factor | ≥600 |
| Channel Separation | ≥70dB |
| Input Sensitivity | 32dB |
| Protection System | Soft Start Protection DC Protection High-Frequency Protection Overheating Protection Short-Circuit Protection Amplitude Limiting Protection Power-On/Power-Off Mute Protection |
| Input Impedance | 20K/10K(balance/unbalance) |
| Output Circuitry | Class D |
| Input Connectors | XRL Connector |
| Output Plug | Speaker Socket |
| AC Power Operating Range | 100V~240V/50-60Hz |
| Dimensions ( HxWxD ) | 88 x 483 x 462mm |
| Packing Size ( HxWxD ) | 160 x 615 x 516mm |
| Net Weight | 11.4 kg |
| Gross Weight | 13.6 kg |
