VH118SUB
• Drivers
1x 18" bass
• Max SPL (Peak)
134dB
- Commodity name： VH118SUB
Overview
VH118SUB is a high-performance active subwoofer designed to deliver deep, impactful bass with a single 18-inch bass driver. With a frequency response extending down to 30Hz, it ensures precise reproduction of low-end frequencies, adding depth and power to any performance. The 700W AES-rated power and 3-channel DSP Class D amplifier provide efficient and controlled bass output, while the maximum SPL of 134dB peak allows it to fill large venues with resonant, powerful low frequencies. Perfectly paired with VH210, it extends the low-frequency range, offering essential reinforcement for a balanced, immersive audio experience.
Specifications
| Drivers | 1 x 18"(460mm) bass |
| Frequency Response (-5dB) | 30Hz~300Hz |
| Dispersion (-6dB) | / |
| Max SPL | 128dB (continuous)/134dB (peak) |
| Rated Power (AES) | 700W |
| Amplifier Circuitry | 3 Channel DSP, Class D |
| Amplifier Input Sensitivity | 1V |
| Output Power | 4Ω/2 x 800W + 4Ω/1600W |
| Impedance | 8Ω |
| Dimensions ( HxWxD ) | 505 x 620 x 650 mm |
| Net Weight | 46 kg |
Dimensions
