T24N
• Drivers
LF: 2×12" neodymium
HF: 1×1.4" titanium diaphragm compression driver
• Dispersion
Hor.60°x Vert.40°C
• Max SPL (Peak)
141dB at PASSIVE
LF 140dB /HF 138dB at BIAMP
- Commodity name： T24N
Overview
T24N delivers outstanding SPL in a compact form, featuring dual 12" neodymium woofers and a 1.4" titanium diaphragm driver. With switchable passive/bi-amp modes and a rotatable horn (60°×40° or 90°×50°), it offers flexible deployment and consistent directivity. Exceptional low-mid punch, smooth highs, and low distortion ensure natural, high-fidelity reproduction even at peak levels. Ideal for demanding applications requiring powerful output, wide coverage, and compact design.le.
Specifications
| Drivers | LF 2×12" (315mm)neodymium HF 1×1.4" titanium diaphragm compression neodymium driver |
| Frequency Range(±3dB) | PASSIVE 100Hz～18.5KHz |
| Frequency Range(-10dB) | PASSIVE 65Hz～18.5KHz |
BIAMP LF 65Hz～2.0KHz(-10dB) HF 900Hz～18.5KHz(-10dB) | |
| Dispersion(-6dB) | Hor.60°x Vert.40° |
| Sensitivity (1M/1W) | PASSIVE 107dB |
| BIAMP LF 107dB HF 112dB | |
| Max SPL | PASSIVE 135dB(continuous)/141dB(peak) |
BIAMP LF 134dB(continuous)/140dB(peak) HF 132dB(continuous)/138dB(peak) | |
| Rated Power (AES) | PASSIVE 1200W |
| BIAMP LF 1000W HF 150W | |
| PEAK Power | PASSIVE 2400W |
| BIAMP LF 2000W HF 300W | |
| Impedance | PASSIVE 4Ω |
| BIAMP LF 4Ω HF 8ΩC | |
| Dimensions ( HxWxD ) | 706 x 440 x 440 mm |
| Net Weight | 35.5 kg |
Dimensions
