- Commodity name： C212SA
Overview
C212SA is a high-efficiency active subwoofer with dual 12" long-excursion drivers and a precision-engineered bass reflex design. It delivers powerful low-end extension and punch, minimizing port noise through large optimized vents. Compact yet impactful, it’s ideal for venues needing deep, clean bass reinforcement. Designed to match the C6 line array, the C212SA forms a versatile full-range system for mobile events, fixed installations, and performance spaces requiring clarity and power across the entire frequency spectrum.
Specifications
| Drivers | 2x12"(300mm) bass |
| Frequency Response (-6dB) | 40Hz～300Hz |
| Sensitivity (1M/1W) | 98dB |
| Max SPL | 127.6dB (continuous)/133.6dB (peak) |
| Rated Power (AES) | 900W |
| PEAK Power | 3600W |
| Amplifier Circuitry | Class D |
| Amplifier Frequency Response (0/-5dB) | 20Hz~20kHz |
| DSP Sampling Rate | 96kHz/24-bit |
| DSP Input Channels | 2 in 3 out |
| AC Power Operating Range | 220～240V，50/60Hz |
| SNR | ≥95dB |
| THD | ≤0.05% |
| Input/Output Connectors | XLR-F/M |
| Amplifier Output Connectors | 2 four-core professional speaker socket MLF Out 1+ 1- HF Out 2+ 2- |
| Dimensions ( HxWxD ) | 700 x 380 x 540 mm |
Dimensions
You May Like
• Drivers
MLF: 1 x 6.5"
HF: 1×1.5″ (38mm), 1″throat compression driver
• Dispersion
Hor.90°× Vert.15°
• Max SPL（Peak）
MLF:120dB HF:128dB
Applications
